NET CAMERA 4MP HYBRID BULLET/TPC-DF1241-TB3F4-DWS8V1 DAHUA
DAHUA · 6937552429031
—
The invoice is sent as soon as you order.
Out of stock
- Payment: bank transfer or cash on delivery
- Delivery: 1–3 working days, anywhere in Latvia
- Warranty: 36 mo.
- Invoice: with every order
- EAN
- 6937552429031
- Brand
- DAHUA
Description
Featuring thermal and visible channels, Eureka series thermal network camera offers various AI functions such as tripwire, intrusion, call detection, smoking detection, and temperature measurement. It can be used in short-distance monitoring scenes such as perimeter protection and heat monitoring, which provides an all-in-one video surveillance solution for small and medium scenes. The camera is widely applied in waste, laundry, warehouse, and more.
- Vanadium oxide uncooled focal plane detector
- 4Megapixel progressive scan CMOS
- AI functions: heat detection, tripwire, human/vehicle classification, smoking detection, and call detection
- Temperature measurement range of –20 °C to +550 °C
- Flexible rules and alarms
- Built-in white light and audio alarm
- Remote auxiliary management
- Dual image fusion (visible and thermal channels)
- Wide input voltage 12 VDC ± 20%, and PoE
- IP67 rated
Specifications
| Form factor | Dome |
| IP rating | IP67 |
| Mounting type | Ceiling/wall |
| Colour | White |
| Alarm input/output | Yes |
| Connection technology | Wired |
| Day/night mode | Yes |
| Placement | Indoor & outdoor |
| Thermal sensitivity (NETD) | 40 mK |
| Product type | IP security camera |
| Digital Wide Dynamic Range (DWDR) | Yes |
| Shutter speed | 1/30000 - 1 s |
| Camera shutter type | Electronic |
| Horizontal field of view | 50.6 ° |
| Lens viewing angle, horizontal | 71.2 ° |
| Lens viewing angle, vertical | 52 ° |
| Minimum illumination | 0 lx |
| Camera pixel pitch | 12 µm |
| Vertical field of view | 37.8 ° |
| White balance | Auto/Indoor/Manual/Natural/Outdoor/Street lamp |
| Thermal camera resolution | 256 x 192 pixels |
| Optical sensor size | 1/2.7 " |
| Sensor type | CMOS |
| Thermal sensor type | Noise equivalent temperature difference (NETD) |
| Aperture number (thermal module) | 1 |
| Closest focusing distance | 1 m |
| Digital zoom | 16 x |
| Focal length | 4 mm |
| Infrared spectral band | 8 - 14 µm |
| Maximum aperture | 1.6 |
| Number of lenses | 1 |
| IR LED type | IR |
| Night vision | Yes |
| Infrared night vision range | 30 m |
| Backlight compensation | Yes |
| Gain control type | Auto/Manual |
| Highlight compensation | Yes |
| Maximum resolution | 2336 x 1752 pixels |
| Noise reduction | Yes |
| Noise reduction technology | 2D noise reduction,3D noise reduction |
| Region of Interest (ROI) encoding | Yes |
| Total megapixels | 4 MP |
| Video compression formats | H.264/H.264H/H.265/M-JPEG |
| Signal-to-noise ratio (SNR) | 55 dB |
| Voice codecs | G.711a/G.711Mu/PCM |
| Bluetooth | No |
| Ethernet type | Fast Ethernet |
| Ethernet LAN | Yes |
| Networking standards | IEEE 802.1x |
| Number of users | 10 user(s) |
| Network protocols | HTTPS; HTTP; TCP; ARP; RTSP; RTP; UDP; RTCP; SMTP; FTP; DHCP; DNS; DDNS; PPPOE; IPv4/v6; SNMP; QoS; UPnP; NTP |
| Wi-Fi | No |
| Built-in HDD | No |
| Card reader | Yes |
| Supported memory cards | MicroSD (TransFlash) |
| Maximum memory card size | 256 GB |
| Ethernet (RJ-45) ports | 1 |
| RS-485 count | 2 |
| Alarm input channels | 2 |
| Alarm output channels | 2 |
| HTTPS encryption | Yes |
| Human and vehicle targets classification | Yes |
| Intelligent video surveillance features | Heat map/Intrusion/Tripwire |
| Password protection | Yes |
| Temperature measurement accuracy | 2 °C |
| Temperature measurement range | -20 - 550 °C |
| DC output current | 1.2 A |
| Output voltage | 12 |
| Power consumption (max) | 6.8 W |
| Power consumption (PoE) | 5.7 W |
| Power consumption (typical) | 4.6 W |
| Power source | PoE,DC |
| Operating humidity | 0 - 95 % |
| Operating temperature | -30 - 60 °C |
| Storage temperature | -30 - 70 °C |
| Diameter | 122 mm |
| Height | 112 mm |
| Weight | 850 g |
| Number of cameras | 1 |
| Audio input | 1 |
| Audio output | 1 |
| Supported browsers | Google / Firefox |
| Maximum data transfer rate | 100 Mbit/s |
