NET SWITCH 4PORT POE+ T8504-R/01633-001 AXIS
About this product
AXIS T8504-R Industrial PoE Switch is a 4-port managed industrial PoE Gigabit switch. In addition, the switch is equipped with two RJ45 and two SFP data ports that allows for extra devices to be connected. The switch uses the same intuitive administrator interface as AXIS T85 PoE Network Switch Series. The ruggedized switch is perfect for challenging environments when mounted inside a surveillance cabinet. It is designed to withstand shock, vibrations and temperatures from -40 °C to 75 °C (-40 °F to 167 °F), making it perfect for high demanding installations such as alongside highways and tunnels.
- 60 W per port, 240 W power budget; Compliant with High PoE 60 W; Dual DC power redundancy; High availability with Rapid Ring; NEMA TS-2 compliant
Specifications
- Unit Calculated Weight
- 1.06 kg
- Unit Calculated Volume
- 0.004641 cubm
- Units per Shipping Box
- 1
- Category Code
- SWI
- Unit Box Height
- 0.21
- Unit Box Length
- 0.26
- Unit Box Width
- 0.085
Management features
- Switch type
- Managed
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity
- 4
- Basic switching RJ-45 Ethernet ports type
- Gigabit Ethernet (10/100/1000)
- Console port
- RJ-45
- Fiber optic connector
- SFP
- Power connector
- DC-in jack
Network
- 10G support
- No
- Networking standards
- IEEE 802.1Q/IEEE 802.1x
- VLAN support
- Yes
Data transmission
- Jumbo frames
- 9216
- Jumbo frames support
- Yes
- MAC address table
- 8000 entries
- Switching capacity
- 16 Gbit/s
- Throughput
- 11.9 Mpps
Security
- Authentication type
- RADIUS
- Password protection
- Yes
- Security algorithms
- HTTPS/SNMP/SNMPv3
Design
- Housing material
- Aluminium
- Product colour
- Black
Power
- DC input voltage
- 54 - 57 V
- Surge protection
- Yes
Power over Ethernet (PoE)
- Power over Ethernet (PoE)
- Yes
- Power over Ethernet (PoE) ports quantity
- 4
- Power over Ethernet (PoE) power per port
- 60 W
- Total Power over Ethernet (PoE) budget
- 240 W
Operational conditions
- Operating relative humidity (H-H)
- 5 - 95 %
- Operating temperature (T-T)
- -40 - 75 °C
- Storage temperature (T-T)
- -40 - 85 °C
Weight & dimensions
- Depth
- 130 mm
- Height
- 135 mm
- Weight
- 600 g
- Width
- 62 mm
Packaging content
- Quick start guide
- Yes
Packaging data
- Mounting brackets included
- Yes
Certificates
- Certification
- EN 55032, EN 55024, FCC, ICES-003, VCCI, RCM AS/NZS CISPR 32, EN 50121-4, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, EN 61000-6-3, EN 61000-6-4 IEC 62236-4, IEC/EN/UL 60950-1, IEC 60068-2-6, IEC 60068-2-27, 60068-2-31, NEMA TS-2-2003
Logistics data
- Harmonized System (HS) code
- 85176990
Identifiers
- Brand
- AXIS
- Categories
- Networking
- Model
- 01633-001
- EAN
- 7331021066199
