Power Supply, TECNOWARE, ATX, PC, 180 - 264 V, 650 W, FAL651FSP12
TECNOWARE · 8026475179944
—
The invoice is sent as soon as you order.
Out of stock
- Payment: bank transfer or cash on delivery
- Delivery: 1–3 working days, anywhere in Latvia
- Warranty: 24 mo.
- Invoice: with every order
- EAN
- 8026475179944
- Brand
- TECNOWARE
Description
Internal power supply for personal computer, power 650W, input voltage 230 Vac, 50/60 Hz, conforms to ATX 12V v.2.31 specifications, main switch, surge protection, overload protection, short circuit protection, high MTBF, high reliability, quiet operation, 12 cm silent fan, temperature control of fan speed, Flat type connection cables from 500mm to 800mm, 1 x 20+4-pin connector, 1 x 12V 4+4-pin connector, 1 x 6+2 PCI-E connector, 2 x Molex connectors, 4 x Sata connector, dimensions 150x140x86 mm, weight 1.0 Kg, black color, CE certification, RoHS.
- Internal Power Supply for Computers
- High Efficiency (>85%) and High Operation Noise
- Active PFC >0.9
- Dimensions: 140x86x150 mm (WxHxD)
- Input voltage 230 Vac 50Hz
- Temperature control of the fan speed
- Flat connection cables from 500mm to 800mm
- Surge protection
- Overload protection
- Short circuit protection
Specifications
| Input frequency | 47 - 63 Hz |
| Input voltage | 180 - 264 V |
| Efficiency | 85 % |
| Max output current (+12V) | 26 A |
| Max output current (+3.3V) | 25 A |
| Max output current (+5V) | 26 A |
| Max output current (+5Vsb) | 2.5 A |
| Max output current (-12V) | 0.8 A |
| Power Factor Correction (PFC) type | Active |
| Power protection | Overload/Short circuit/Surge protection |
| Rated power | 650 W |
| CPU power connector (4+4 pin) | Yes |
| Motherboard power connector | 24-pin ATX |
| Number of SATA power connectors | 4 |
| PCI Express power connectors (12+4 pin) | 1 |
| Molex power connectors | 2 |
| 80 PLUS certification | No |
| ATX version | 2.31 |
| Form factor | ATX |
| Intended use | PC |
| Cooling type | Active |
| Fan diameter | 120 mm |
| Number of fans | 1 fan(s) |
| On/off switch | Yes |
| Colour | Black |
| Operating temperature | 0 - 40 °C |
| Storage temperature | -15 - 40 °C |
| Depth | 140 mm |
| Height | 86 mm |
| Weight | 1000 g |
| Width | 150 mm |
