Mainboard, MSI, Intel B760 Express, LGA1700, Mini-ITX, Memory DDR5
Mainboard, MSI, Intel B760 Express, LGA1700, Mini-ITX, Memory DDR5, Memory slots 2, 1xPCI-Express 16x, 2xM.2, 1xHDMI, 1xDisplayPort, 2xUSB 2.0, 5xUSB 3.2, 1xUSB-C, 1xRJ45, 3xAudio port, MPGB760IEDGEWIFI
MSI · 4711377069632
Rēķins tiek nosūtīts uzreiz pēc pasūtījuma.
- Apmaksa: pārskaitījums vai maksājums saņemot
- Piegāde: 1–3 darba dienas, visā Latvijā
- Garantija: 36 mēn.
- Rēķins: katram pasūtījumam
- EAN
- 4711377069632
- Zīmols
- MSI
Apraksts
MPG B760I EDGE WIFI employs silver white color scheme to show off different personality and identity. Besides being stylish, it is also powerful.
BE AHEAD, POP YOUR STYLE
The MPG series brings out fashionable products by showing extremely unique styles and expressing a conceited attitude towards the challenge of the gaming world. With extraordinary performance and style, the MPG series defines the future of gaming fashion.
Extended Heatsink
Extended Heatsink enlarges the surface of heat dissipation, ensuring even high-end processors to run in full speed.
Pump Fan Support
Control watercooling pump speeds for best flow and noise control.
7W/mK Thermal Pad
High quality 7W/mK MOSFET thermal pads and extra choke thermal pads ensure all cores running in high performcance.
M.2 Shield Frozr
Keeps M.2 SSDs safe while preventing throttling, making them run faster.
8-Layer Server Grade PCB
8-layer PCB with 2oz thickened copper provides higher performance and long-lasting system stability without any compromise.
LIGHTNING GEN 5 PCI-E
Doubling over the previous generation, the bandwidth of a x16 interface can reach 128GB/s.
SMT PCIE 5.0 SLOT
The advanced SMT(Surface Mount Technology) PCIE slot diminish interference and electrical noise, fully support the PCI-E 5.0 signal.
REINFORCED,
HEAVY SOLDERED CONNECTIONS
Secure to the motherboard with extra solder points and support the weight of heavy graphics cards.
FAST AND FUTURE-READY STORAGE
MSI MPG series motherboards support all the latest storage standards, which allows users to connect any ultra-fast storage device. Start games faster, load levels faster and have a real advantage over your enemies.
- Supports 13th /12th Gen Intel® Core™ / Pentium® / Celeron® processors for LGA 1700 socket
- Supports DDR5 Memory, up to 7200+(OC) MHz
- Lightning Fast Game experience: PCIe 5.0 slots, Lightning Gen 4 x4 M.2, USB 3.2 Gen 2
- Enhanced Power Design: Direct 8+1+1 phases power, Core Boost, Memory Boost
- Premium Thermal Solution: Enlarged heatsink, MOSFET thermal pads rated for 7W/mk, additional choke thermal pads and M.2 Shield Frozr are built for high performance system and non-stop gaming experience
- 2.5G LAN and Intel Wi-Fi 6E Solution: Upgraded network solution for professional and multimedia use. Delivers a secure, stable and fast network connection
- AUDIO BOOST: Reward your ears with studio grade sound quality for the most immersive gaming experience
- High Quality PCB: 8-layer PCB made by server grade level material
- Pre-installed I/O Shield: Better EMI protection and more convenience for installation
Specifikācija
| Audio čips | Realtek ALC897 |
| Audio kanālu | 7.1 kanāli |
| Komponente paredzēta | PC |
| Čipkomplekts | Intel B760 |
| Čipkomplekta ģimene | Intel |
| Formas faktors | mini ITX |
| Enerģijas avots | ATX |
| Krāsa | Black/Silver |
| Atbalstītās Windows operētājsistēmas | Windows 10/Windows 11 |
| Savienojams procesora sērijas | Intel® Celeron®/Intel® Pentium® Gold |
| Maksimālais SMP procesoru skaits | 1 |
| Procesora ražotājs | Intel |
| Procesora ligzda | LGA 1700 |
| ECC saderība | Non-ECC |
| Maksimālā atmiņa | 96 GB |
| Atmiņas kanāli | Dual-channel |
| Atmiņas formas faktors | DIMM |
| Atmiņas slotu skaits | 2 |
| Atmiņas frekvence (maks.) | 7200 MHz |
| Atbalstītie atmiņas pulksteņa ātrumi | 4800/5000/5200/5400/5600/5800/6000/6200/6400/6600/6800/7000/7200 MHz |
| Atbalstītie atmiņas tipi | DDR5-SDRAM |
| RAID līmeņi | 0/1/10/5 |
| RAID atbalsts | Jā |
| Atbalstītās diska saskarne | M.2,SATA III |
| Iebūvēta grafika | Nē |
| ATX enerģijas savienotājs | Jā |
| CPU ventiliatora savienotājs | Jā |
| Priekšējais panelis audio savienotājs | Jā |
| Priekšējā paneļa pieslēgvieta | Jā |
| SATA savienotāji | 4 |
| RGB LED pinheader | Jā |
| TPM galvene | Jā |
| Iekšējie USB 2.0 savienotāji | 2 |
| Iekšējie USB 3.2 Gen 1 savienotāji | 2 |
| USB 3.2 Gen 2 savienotāji | 1 |
| DisplayPort versija | 1.4 |
| DisplayPort portu skaits | 1 |
| Ethernet (RJ-45) portu skaits | 1 |
| HDMI portu skaits | 2 |
| HDMI versija | 2.1 |
| USB 2.0 portu skaits | 2 |
| USB 3.2 Gen 1 Type-A portu skaits | 4 |
| USB 3.2 Gen 2 Type-A portu skaits | 1 |
| Bluetooth | Jā |
| Bluetooth versija | 5.3 |
| Ethernet veids | 2.5 Gigabit Ethernet |
| Ethernet LAN | Jā |
| Augstākais Wi-Fi standarts | Wi-Fi 6E (802.11ax) |
| Wi-Fi | Jā |
| Wi-Fi standardi | 802.11a/802.11g/Wi-Fi 4 (802.11n)/Wi-Fi 5 (802.11ac)/Wi-Fi 6 (802.11ax)/Wi-Fi 6E (802.11ax) |
| M.2 slotu skaits | 2 |
| PCI Express x1 (Gen 3.x) spraugas | 2 |
| BIOS atmiņas lielums | 256 Mbit |
| BIOS veids | UEFI AMI |
| SMBIOS versija | 3.5 |
| Dziļums | 170 mm |
| Platums | 170 mm |
| Modelis | MPG B760I EDGE WIFI |
