DISPLAY LCD 46" VM46B/LH46VMBUBGBXEN SAMSUNG

Характеристики

Unit Calculated Weight

21 kg

Unit Calculated Volume

0.2198 cubm

Units per Shipping Box

1

Summary

Samsung VM46B-U. Display diagonal: 116.8 cm (46"), Display resolution: 1920 x 1080 pixels, Display technology: LCD, Display brightness: 500 cd/m², HD type: Full HD, Operating hours (hours/days): 24/7. Product colour: Black

Vendor Homepage

https://www.samsung.com/

Category Code

VWD

Unit Box Height

0.71

Unit Box Length

1.19

Unit Box Width

0.26

Model name

VM46B

Model

VM46B

Display

Aspect ratio

16:9

Contrast ratio (dynamic)

45000:1

Contrast ratio (typical)

1200:1

Display brightness

500 cd/m²

Display diagonal

46 "

Display resolution

1920 x 1080 pixels

Display technology

LCD

HD type

Full HD

Horizontal scan range

62.7 - 72.3 kHz

Operating hours (hours/days)

24/7

Panel type

IPS

Pixel frequency

82 MHz

Pixel pitch

0.53 x 0.53 mm

Response time

0.008 s

Vertical scan range

57 - 63 Hz

Viewing angle, horizontal

178 °

Viewing angle, vertical

178 °

Design

Bezel width (bottom)

2.25 mm

Bezel width (side)

1.25 mm

Bezel width (top)

2.25 mm

Orientation

Horizontal/Vertical

Panel colour

Black

Panel mounting interface

600 x 400 mm

Placement supported

Indoor

Product colour

Black

VESA mounting

Yes

Ports & interfaces

Audio input

Yes

Audio output

Yes

DisplayPort version

1.2

DisplayPorts quantity

1

DVI port

Yes

Ethernet LAN

Yes

Ethernet LAN (RJ-45) ports

1

HDCP

Yes

HDCP version

2.2

HDMI ports quantity

2

HDMI version

2.0

IR input ports quantity

1

RS-232 input ports

1

RS-232 output ports

1

RS-232C

Yes

USB port

Yes

USB ports quantity

1

Power

AC input frequency

50 - 60 Hz

AC input voltage

100 - 240 V

Energy consumption (SDR) per 1000 hours

128 kWh

Energy efficiency class (SDR)

G

Energy efficiency scale

A to G

Power consumption (typical)

160 W

Logistics data

Harmonized System (HS) code

85285210

Operational conditions

Operating relative humidity (H-H)

10 - 90 %

Operating temperature (T-T)

0 - 40 °C

Sustainability

Certification

FCC (USA) Part 15, Subpart B Class ACE (Europe) : EN55032 : 2012 or 2015 EN55024:2010 or EN 55035:2017VCCI (Japan) : VCCI CISPR32:2016 Class BKCC/EK (Korea) : Tuner : KN13 / KN20Tunerless : KN22 / KN24BSMI (Taiwan) : CNS13438 ( ITE EMI ) Class A / CNS14

Weight & dimensions

Depth

69.9 mm

Height

577 mm

Weight

15700 g

Width

1022 mm

Packaging data

Package depth

257 mm

Package height

719 mm

Package weight

22200 g

Package width

1193 mm

Energy Efficiency

Data Sheet (Link)

https://eprel.ec.europa.eu/api/product/1192451/fiches?language=EN

Energy efficiency class

G

EPREL Registration Number

1192451

EPREL Version Number

3

Идентификаторы

Бренд

SAMSUNG

Категории

Телевизоры

Модель

LH46VMBUBGBXEN

EAN

8806094366082
