BE QUIET
Power Supply|BE QUIET|ATX|PC|100 - 240 V|1200 W|BP021EU
О товаре
No compromise silence and performance
Dark Power 14 1200W claims nothing less than the top spot. This powerhouse features a high-performance heat sink design with an integrated fan and can be operated in either active or semi-passive mode.
- 80 PLUS® Titanium and Cybenetics Titanium efficiency (up to 95.42 %)
- ATX 3.1 PSU with full support for PCIe 5.1 GPUs and GPUs with 6+2-pin connector
- Active and semi-passive cooling can be selected with the push of a button
- Aluminum heat sink to support the semi-passive cooling concept and improve the longevity of the components
- Silent Wings fan for virtually inaudible operation
- Full bridge + Synchronous Rectifier + LLC technology provides unmatched signal stability and extremely high efficiency
- Button to switch between single and multi-rail operation
- Full-mesh front with funnel-shaped air inlet upholds the high air circulation abilities
- Modular cable management for maximum convenience
- Product conception, design and quality control in Germany
Характеристики
- Unit Calculated Weight
- 4.99 kg
- Unit Calculated Volume
- 0.01318 cubm
- Units per Shipping Box
- 4
- Units per Pallet
- 0
- Summary
- be quiet! Dark Power 14 1200 W - 80 Plus Titanium. Total power: 1200 W, AC input voltage: 100 - 240 V, Peak power: 1300 W. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 60 cm, SATA power cable length: 600,750,900,1050 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Titanium. Product colour: Black, Cooling type: Active, Fan diameter: 13.5 cm. Compliance certificates: CB, Federal Communications Commission (FCC), RoHS, TÜV mark, UKCA, WEEE, cTUVus
- Vendor Homepage
- https://www.bequiet.com/en/download/products
- Category Code
- PSU
- Unit Box Height
- 0.127
- Unit Box Length
- 0.354
- Unit Box Width
- 0.232
Power
- AC input frequency
- 50/60 Hz
- AC input voltage
- 100 - 240 V
- Combined power (+12V)
- 1200 W
- Combined power (+3.3V)
- 120 W
- Combined power (+5V)
- 120 W
- Efficiency
- 93.1 %
- Hold time
- 19.5 ms
- Max output current (+12V1)
- 33 A
- Max output current (+12V2)
- 33 A
- Max output current (+12V3)
- 45 A
- Max output current (+12V4)
- 45 A
- Max output current (+3.3V)
- 25 A
- Max output current (+5V)
- 24 A
- Max output current (+5Vsb)
- 3 A
- Max output current (-12V)
- 0.5 A
- Maximum input current (@110V)
- 10 A
- Maximum input current (@220V)
- 5 A
- Number of +12V rail(s)
- 4
- Peak power
- 1300 W
- Power factor
- 0.98
- Power protection features
- Over current/Over voltage/Overheating/Overload/Short circuit/Surge & inrush protection (SIP)/Under voltage
- Total power
- 1200 W
Ports & interfaces
- ATX power connector (20+4 pin)
- Yes
- Cabling type
- Fully-Modular
- CPU power cable length
- 700 mm
- CPU power connector (4+4 pin)
- Yes
- EPS power connector (4+4 pin)
- Yes
- EPS power connector (8-pin)
- Yes
- Motherboard power cable length
- 600 mm
- Motherboard power connector
- 20+4 pin ATX
- Number of SATA power cables
- 4
- Number of SATA power connectors
- 13
- PCI Express connector
- Yes
- PCI Express power cable length
- 600 mm
- PCI Express power connectors (12-pin)
- 2
- PCI Express power connectors (6+2 pin)
- 4
- Peripheral (Molex) power cable length
- 1050/900 mm
- Peripheral (Molex) power connectors (4-pin)
- 2
- SATA power cable length
- 1050/600/750/900 mm
Performance
- 80 PLUS certification
- 80 PLUS Titanium
- ATX version
- 3.1
- Bearing technology
- FDB
- EPS version
- 2.92
- Mean time between failures (MTBF)
- 100000 h
- Noise level
- 21.1 dB
- Power supply unit (PSU) form factor
- ATX
- Purpose
- PC
Design
- Cooling type
- Active
- Fan diameter
- 135 mm
- Fan speed
- 0 - 2100 RPM
- Number of fans
- 1 fan(s)
- On/off fan switch
- Yes
- On/off switch
- Yes
- Product colour
- Black
Operational conditions
- Operating temperature (T-T)
- 0 - 40 °C
Certificates
- Compliance certificates
- CB/cTUVus/Federal Communications Commission (FCC)/RoHS/TÜV mark/UKCA/WEEE
Weight & dimensions
- Depth
- 175 mm
- Height
- 86 mm
- Weight
- 2300 g
- Width
- 150 mm
Packaging data
- Manual
- Yes
- Manual languages
- English/French/German/Italian/Japanese/Polish/Russian/Simplified Chinese/Spanish/Thai/Ukrainian
- Package depth
- 126 mm
- Package height
- 355 mm
- Package weight
- 3700 g
- Package width
- 230 mm
Technical details
- Sustainability certificates
- ENERGY STAR/ErP/Triman
Logistics data
- Products per shipping (inner) case
- 4 pc(s)
- Shipping (inner) case height
- 260 mm
- Shipping (inner) case length
- 528 mm
- Shipping (inner) case net weight
- 20140 g
- Shipping (inner) case width
- 368 mm
Other features
- Cable ties included
- Yes
- Screws included
- Yes
Идентификаторы
- Бренд
- BE QUIET
- Модель
- BP021EU
- EAN
- 4260052192030
